MD-B20/B25/B30/B40/B50 - Crusher Machine
Economical Powerful Crusher Machine MD-B Type
Description
Economical Powerful Crusher Machine MD-B Type
Wan Ming is committed to being one of the world's leading crusher manufacturer. The Economical Powerful Crusher Machine is specially build to crush plastic products, such as pet bottle, plastic packaging, plastic containers. As a plastic crusher manufacturer, we offer convenient and time-saving machine.
| Type | MD-B20 | MD-B25 |
|---|---|---|
| Motor(HP) | 20-30 HP | 30-40 HP |
| Into Size(mm) | 500 x 500 mm | 630 x 500 mm |
| Rotary Cutter | 3 or 6 pcs | 3 or 6 pcs |
| Stationary Cutter | 2 pcs | 2 pcs |
| N.W.(kgs) | 1600 kgs | 1800 kgs |
| LxWxH (mm) | 2253 x 1197 x 2310 mm | 2250 x 1322 x 2395 mm |
| Rotary Diameter (mm) | 460 mm | 460 mm |
| Capacity | 400-700 kgs/hour | 500-800 kgs/hour |
| Type | MD-B30 | MD-B40 |
|---|---|---|
| Motor(HP) | 30-40 HP | 40-50 HP |
| Into Size(mm) | 765 x 500 mm | 1000 x 500 mm |
| Rotary Cutter | 6 or 9 pcs | 12 pcs |
| Stationary Cutter | 2 x 2=4 pcs | 2 x 2=4 pcs |
| N.W.(kgs) | 2100 kgs | 2300 kgs |
| LxWxH (mm) | 2250 x 1447 x 2395 mm | 2250 x 1572 x 2515 mm |
| Rotary Diameter (mm) | 460 mm | 460 mm |
| Capacity | 600-900 kgs/hour | 700-1000 kgs/hour |
| Type | MD-B50 |
|---|---|
| Motor(HP) | 50-60 HP |
| Into Size(mm) | 1250 x 500 mm |
| Rotary Cutter | 15 pcs |
| Stationary Cutter | 2 x 2=4 pcs |
| N.W.(kgs) | 2500 kgs |
| LxWxH (mm) | 2250 x 1697 x 2665 mm |
| Rotary Diameter (mm) | 460 mm |
| Capacity | 800-1200 kgs/hour |
-
